GE B90 User Manual

D-2 B90 LOW IMPEDANCE BUS DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL
REVISION HISTORY APPENDIX D: MISCELLANEOUS
D
Table D-2: Major changes for B90 manual version AF1 (English)
Table D-3: Major changes for B90 manual version AE3 (English)
1601-0115-S3 5.5x 12 March 2008 URX-260
1601-0115-T1 5.6x 27 June 2008 08-0390
1601-0115-U1 5.7x 29 May 2009 09-0938
1601-0115-U2 5.7x 30 September 2009 09-1165
1601-0115-V1 5.8x 29 May 2010 09-1457
1601-0115-V2 5.8x 04 January 2011 11-2237
1601-0115-W1 5.9x 12 January 2011 11-2227
1601-0115-X1 6.0x 21 December 2011 11-2840
1601-0115-X2 6.0x 5 April 2012 12-3254
1601-0115-Y1 7.0x 30 September 2012 12-3529
1601-0115-Y2 7.0x 11 November 2012 12-3601
1601-0115-Z1 7.1x 30 March 2013 13-0126
1601-0115-AA1 7.2x 1 August 2013 13-0401
1601-0115-AB1 7.3x 7 November 2014 14-1408
1601-0115-AB2 7.3x 1 September 2015 15-2215
1601-0115-AC1 7.40x 8 December 2016 16-3319
1601-0115-AE1 7.41x 31 January 2017 17-3427
1601-0115-AE3 7.4x 28 April 2017 17-3561
1601-0115-AF1 7.6x 30 June 2017 17-3779
Page Description
--- General revision
--- Updated "faceplate" to "front panel" for consistency and to reflect web site
--- Added graphical front panel option to order codes and specifications in chapter 2, Interfaces chapter 4, Settings chapter 5,
Actual Values chapter 6
--- Added PEAP-GTC and PAP protocols for authenticating user logins when using a RADIUS server. Added to Settings > Product
Setup > Security > RADIUS Authentication Method and to Modbus memory map and F codes.
--- Updated Contact Inputs from 96 to 120 and Contact Outputs from 64 to 72 in Product Description in chapter 2 and FlexLogic
operands table in chapter 5
3-36 Updated RS422 and Fiber Interface Connection figure for the clock channels (from 7a and 7b to 1a and 1b)
3-67 Added Connect to a D400 Gateway section
4-42 Updated LED Labelling instructions for the new Front Panel Label Designer
4-50 Added Standard Front Panel section for labelling LEDs and pushbuttons
5-98 Added USB Port section to enable/disable the USB port on the graphical front panel
5-110 Updated User-programmable Pushbuttons section as per specifications
10-5 Added Convert Device Settings section
10-7 Added Copy Settings to Other Device section
10-15 Added Replace Front Panel section for retrofit with the new graphical front panel
Page Description
--- General revision
2- Updated order codes
10-5 Added Copy Settings to Other Device section
Manual P/N B90 revision Release date ECO
