OPM_LPS_33E_10K_30K_4CN_V010.doc 37/82 Operating Manual LP 33 / 10-20-30 kVA
5.2 LAYOUT LP 33 / 30 KVA
Fig. 5.2.1-1 General view
Fig. 5.2.1-2 Front view
Fig. 5.2.1-3 Side view
Fig. 5.2.1-4 Control panel
SGT4000_030_UPS without protections_01GB
SNMP Card (option)
RPA board (option)
Customer Interface (option)
Relay Card
Serial port RS232
Total Off push-button
(Manual Bypass)
Output switch Q1
Output switch Q1
Output switch Q2
(Rectifier Input)
Fuses F9 - F10 - F11
(Battery)
Identification data label
Fig. 5.2.1-5 Front view without panels
Fig. 5.2.1-6 Power connection view
