OPM_LPS_33E_10K_30K_4CN_V010.doc 71/82 Operating Manual LP 33 / 10-20-30 kVA
9 CUSTOMER INTERFACE
9.1 SERIAL PORT J27 - RS232
SGT4000_010-020_UPS+J27_01
J27
Fig. 9.1-1 Serial Port J27 – RS232
Serial Port J27 - RS232
(sub - D, female 9 pin)
Total remote management of the system
using new generation software JUMP (Java
Universal Management Platform) for system
protection and management of systems using
GE UPS’s.
JUMP system is written in JAVA and
supports virtually all platforms having JAVA
runtime environment version 1.1 or higher.
The serial port J27 - RS232 is enabled on all the units of the parallel system.
Serial port J27 – RS232 connection to PC
Fig. 9.1-2 Serial port J27 - RS232 connection to PC
