– 55 –
Dispenser Drawer
The dispenser drawer holds detergent and fabric
softener, delivering at precise times for the cycle
selected. Water is added to the dispenser from the
ZDWHUYDOYHWR¿OODQGÀXVKWKHFXSV$IWHUWKHYDOYH
WXUQVRȺWKHUHPDLQLQJZDWHULQWKHFXSVLSKRQV
out.
Dispenser Removal
To remove the dispenser, the backsplash water valve
and top cover needs to be removed.
1. Remove the dispenser tray from the dispenser
body.
2. Remover four 1/4 in. hex head screws from the
top cover securing the dispenser body to the top
cover.
3. Push back on the dispenser body to release it
from the top cover.
The dispenser shower insert can also be removed at
this time for cleaning, if necessary.
Dispensers
Bleach Funnel
The bleach funnel directs the liquid bleach to the top
cover, dispensing it between the outer tub and the
basket. There is no water valve to rinse the funnel
after use.
To remove the bleach funnel, reach between the top
cover and tub cover and push up on the bottom of
the funnel.
To install the funnel onto the top cover, the locating
WDEQHHGVWRVOLGHLQWRWKHRSHQLQJ¿UVW7KHQSXVK
down on the funnel to seat into position.
Dispenser
Shower
Dispenser
Drawer
Dispenser
Box
Top Cover
