– 27 –
Fault
Code
Fault Name Description Repair Action
1 Lock Monitor Lid lock didn’t occur or lid lock signal not
seen by control due to lack of connection.
Check the resistance of the lid
lock assembly.
Check the harness for open
wires and or connectors from
the board to the lock assembly.
If lock assembly and harness
prove good at the time of
service, replace the lid lock
assembly.
2 Lid Monitor Control did not get lid closed signal from
switch while motor was moving. Could
mean the switch didn’t close or control
didn’t get the signal because of lack of
connection.
Replace control if this fault
happens repeatedly.
3 Locked Rotor
Monitor
For 5 straight seconds control not seeing
signal changes indicating the motor is
turning while trying to spin.
Could mean the motor isn’t rotating or
Control didn’t get the signal because of lack
of connection.
Physically check the washer
for anything preventing motor
movement.
Check harness and harness
connectors from the control to
the motor.
Verify hall sensor is connected
to the main harness. Put
washer in Service Mode and
run TEST 14, Spin Test. If hall
sensor is bad or disconnected,
the basket will start to spin
normally and then stop spinning
after approximately 5 seconds.
Ensure hall sensor is properly
connected and positioned on
the motor. If basket spins for
approximately 15 seconds, the
hall sensor is most likely NOT
the cause.
TCO should reset in
approximately 45 minutes. If
TCO is tripped, make sure
motor moves freely and that
nothing is jamming it. Replace
motor if it does not.
4 Reset Monitor Control is resetting the software by itself
due to criteria it believes could resolve itself
upon reset.
Check for loose connections at
the control. Reconnect if any
are loose.
Check for recommended house
line voltage to the washer.
Fault Codes
(Continued next page)
)LQGLQJ)DXOW&RGHV
7KHUHDUHGLႇHUHQWIDXOWFRGHVWKDWFDQEHVHQVHGUHIHUWRWKH)DXOW&RGHWDEOHEHORZ7KHFRQWURO
will hold up to 10 faults.
Once in the service mode, rotate the cycle select knob to advance to test number 1, Fault Codes. The
most recent fault, if any are logged, will be displayed.
To Next Page
