– 38 –
After the lid is removed, the lid lever arms can be
slid out from the hinge assemblies. They are the
same, so they cannot be mixed up.
The hinges can be removed without removing the
top cover.
1. Slide the backsplash toward the rear of the
washer to access the hinge mounting screws.
2. Slide a hand between the top cover and the
tub cover and grasp the hinge being removed.
3. Remove two 1/4 in. hex head screws that
secure the hinge to the top cover and slide
the hinge out.
/LG+LQJH
Impeller
The impeller moves clothes around in the basket.
It takes the place of a tall agitator. Impellers
are designed to work best with moving material
around in the basket with low water levels.
Impeller Removal
1. Carefully remove the center cap from the
impeller. This can be done with a pocket
screwdriver or putty knife.
2. Remove the 7/16 hex bolt and slide the
LPSHOOHURႇRIWKHVKDIW7KHVSOLQHGFRXSOHULV
part of the impeller.
,PSRUWDQW The impeller bolt (Part #:
WH02X24374) should be replaced any time it
is removed for service and torqued to 100 in.
pounds.
