Innova 2000 Cardiovascular Imaging System
GE Medical Systems
Pre–Installation Manual
REV 5 pim 2337741–100
37
Table 19 – Recommended Separation Distances for Portable and Mobile RF Communications
Equipment IEC 60601–1–2
Frequency of
Transmitter
150 KHz to 26 MHz 26 MHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5 GHz
Equation
P
V
= d ]
5.3
[
2
P
V
= d ]
5.3
[
2
P
E
= d ]
5.3
[
2
P
E
= d ]
7
[
4
Rated Power of
Transmitter(watts)
DISTANCE
(meters)
DISTANCE
(meters)
DISTANCE
(meters)
DISTANCE
(meters)
10 mW 1.2 1.2 1.2 2.3
100 mW 3.8 3.8 3.8 7.3
1 12 12 12 23 (*)
10 38 38 38 73
100 120 120 120 230
For transmitters rated at a power not listed above, the DISTANCE can be estimated using the equation in the
corresponding column, where P is the power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
Note: These are guidelines. Actual conditions may vary.
1-3-4 LIMITATIONS MANAGEMENT:
Adhering to the distance separation recommended in Figure 4, between 150KHz & 2.5GHz, will
reduce disturbances recorded at the image level, but may not eliminate all disturbances. However,
when installed and operated as specified herein, the system will maintain its essential performance by
continuing to acquire, display, and store diagnostic quality images safely.
(*) For example, a 1W mobile phone (800MHz to 2.5GHz carrier frequency) shall be put 23
meters apart from the
Innova 2000 system (in order to avoid images interferences risks).
1-3-5 USE LIMITATION :
The use of accessories, transducers, and cables other than those specified may result in
degraded ELECTROMAGNETIC COMPATIBILITY of the Innova 2000 system
