Innova 2000 Cardiovascular Imaging System
GE Medical Systems
Pre–Installation Manual
REV 5 pim 2337741–100
80
PRODUCT OR
COMPONENT
MOUNTING
METHOD
WEIGHT/
OCCUPIED
AREA
LOAD
BEARING
AREA
INCHES (MM)
DIMENSIONS
NET
WEIGHT
KG (LBS)
PRODUCT OR
COMPONENT
MOUNTING
METHOD
WEIGHT/
OCCUPIED
AREA
LOAD
BEARING
AREA
INCHES (MM)
HEIGHTWIDTHLENGTH
NET
WEIGHT
KG (LBS)
Detector Chiller
HEAT DRY 1
See Illustration 25
11.14 x
13.82
(283x351)
DL keypad
1.4
(3)
283
(11.55)
300
(11.8)
82
(3.25)
Videostation
VCR (8)
12
(26.5)
370
(14.57)
270
(10363)
144
(5.67)
Note 1: including 353 lbs (160 kg) patient.
2: 420 kg (926 lbs) with SEP III inside.
3: 268 kg (590 lbs) without cine.
4: Depth.
5: With 300 lbs (136 kg) patient.
6: Secured with four supplied 3/4” (19 mm) diameter x 4 – 1/4” (108 mm) floor anchors or
3/4 – 10 x 20”, grade 5 thru bolts (for slab or pan construction).
7: With 2 real time disks or 121.3 kg (325 lbs) and one real time disk.
8: 110 V or 220 V model has the same physical characteristics.
3-2 Positioner and Table Floor Mounting
The distances between the Innova LC Positioner and the Omega TableS are critical for a proper
clinical usage. For this reason, GEMS provides two floor mounting templates to ensure these
components are properly placed in relation to one another.
Refer to the following illustrations for Innova LC Positioner to Omega Table floor mounting details:
2185979 Innova LC positioner and Omega IV Compact or Omega V Long patient table floor
mounting template, Illustration 43.
2127792 Innova LC positioner and Omega V Long patient table floor mounting template
(optional), Illustration 42.
