GE Medical Systems Pre–Installation Manual
REV 5 pim 2337741–100
87
3-3 Innova LC Positioner and Omega Table Floor Preparation Kits (GEMS
supplied)
Illustration 44 – Component Select
VAK – New Structure
END
Floor Plate /
Base Plate
Assembly
2285632
Grout +
Insert Assembly +
Through Bolts
2285053
Grout +
Insert Assembly +
Floor Anchors
2285052
A/C/N Template
2285056
EP Template
2186109
Template
Select Kit
2285054
Grout +
Floor Anchors
2285051
Grout +
Floor Anchors
+ Cable Conduit
2286398
Grout +
Through Bolts
2285646
Assembly &
Separation Select
2285050
Base Plate
Assembly
2285048
All GE supplied vascular system floor preparation are contained in catalog. There are some additional
gantry/table mounting kits based on the on each mounting method: through bolts or floor anchors.
 Base plate assembly (mandatory) 2285048 – Refer to Table 23
 Assembly and separation (Select kit) 2285050 – Refer to Table 24
– Above grade, Floor anchors without insert – 2285051.
– Through bolts without insert – 2285646.
– On grade, Floor anchors – 2286398.
– Above grade, Floor anchors and insert – 2285052.
– Through bolts and insert – 2285053.
– Floor plate / Base plate Assembly – 2285632.
 Templates (select kit) – 2285054 – Refer to Table 25
– A/C/N templates – 2285056.
– EP template – 2186109.
