Innova 2000 Cardiovascular Imaging System
GE Medical Systems
Pre–Installation Manual
REV 5 pim 2337741–100
99
Legend of Illustration:
1 – Innova LC positioner
2 – OMEGA IV Compact patient table
3 – ACAB Cabinet
4 – POSTIT Cabinet
5 – MP Phase IV cabinets
6 – Chiller Coolix 2200 (X–Ray tube housing)
7 – Innova Console
8 – DL Image monitor and keyboard
9 – DL Keypad
10 – DL Flat panel
11 – 17” (43 cm) FFD monitor
12 – Chiller Innova Detector
13 – XT monitor suspension
14 – 21” (53 cm) FFD Monitors put on frame
with System Status Display and monitoring screen
15 – Injector on Pedestal
16 – VCR
17 – Bookcase or bookshelves required for Technical Publications and
special parts and tools.
18 – GEMnet CRS Station
Note: The phone outlet must be located less than 1 meter (3 feet) from the
ACAB Cabinet (3).
Note: It is strongly recommended to reserve the layout for an extra cabinet of size 27”(82cm) wide,
31”(95cm) deep in the technical area, anticipating potential upgrade (UPS for instance).
Note: The size of the Operating (patient) Room as defined in the drawing (Illustration 45) shows
the minimum length acceptable. Anticipating a potential table/TSUI Upgrade, it is strongly
recommended to extend the length by another 2’ 8” (80cm), so that, the Operating Room
length is increased to 21’16”(680cm)
