MA-001 – TRANSFIX-family Installation Manual – Rev 3.0 18-Jan-16 Page 29 of 55
Figure 9—5: Coin cell battery
The following steps describe how to change the battery:
1. Back up the product data – contact your GE representative.
2. Open the inner door to locate the battery on the System board (see Figure 9—5).
3. Slide the battery out of its housing.
4. Replace with a new Panasonic CR2450 3 V 620 mAh coin cell.
5. Close the inner door.
There is a danger of a new battery exploding if installed incorrectly.
Dispose of the used battery in accordance with local regulations — not in a fire
or with household waste. Contact your local waste disposal agency for the
address of the nearest battery deposit site. Perchlorate material — special
handling may apply. See: www.dtsc.ca.gov/hazardouswaste/perchlorate/
