DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
7 - 24 Section 7-7 - Common Diagnostics
7-7-4-7 APS II
These programs are provided for testing the APS IIboard.
7-7-4-8 Keyboard
These programs are provided for testing the Front panel.
NOTE: For the EchoBack test, it is highly recommended to press a button less than two times per a
second.
NOTE: When Abort button is pressed to finish EchoBack test, you have to wait until “Completed..”
message is displayed to proceed other tests.
Table 7-8 FRU Test, APS II Diagnostics Menu
Menu
Descriptions
User
Level Tools
Full Test
Performs all of the APS test listed below All None
HV voltage
stability
Read HV voltage and display HV values. All None
LV voltage
stability
Read HV voltage and display LV values. All None
Table 7-9 FRU Test, Keybaord Diagnostics Menu
Menu
Descriptions
User
Level Tools
FRONT PANEL
Overall
Performs all of the Front Panel tests listed below All None
FRONT PANEL
Revision
Test EEPROM.Send test pattern to write to EEPROM and read.Displays the board
revision of the Front Panel.
All None
ROM
Makes a check of internal ROM check sum. All None
RAM
Writes / reads data over all address of RAM and also makes a check of control
program.
All None
EEPROM
Writes / reads data over all address of EEPROM All None
SWITCH
Test switch in Front Panel. All None
Echoback
Rotate or depress any key, Verify that it is displayed on the 17” LCD monitor. To finish
the test, press "Abort" key and wait until complete message appears.
All None
