GE Power Management MDP Digital Time Overcurrent Relay B-
1
GEK-100682D B CHANGE NOTES
B
BCHANGE NOTES B.1 REVISION HISTORY
B.2 ADDITIONS TO MDP MANUAL
Table B–1: REVISION HISTORY
MANUAL P/N MDP REVISION RELEASE DATE ECO
GEK-100604 --- --- ---
GEK-100604A --- --- ---
GEK-100604B --- --- ---
GEK-100604C A --- ---
GEK-100682
replaces GEK-100604C
A February 1995 ---
GEK-100682A A March 1995 ---
GEK-100682B B August 1996 ---
GEK-100682C D March 1997 ---
GEK-100682D D September 8, 2000 MDP-003
Table B–1: ADDITIONS TO MDP MANUAL GEK-100682D
PAGE IN
GEK-100682C
ADDITION
(to GEK-100682D)
Title Added GE Power Management contact information on title page.
Title Added ISO-9000 registration seal.
4 Figure 1-1: SINGLE LINE DIAGRAM
5 Added phase current ranges to ORDER CODES (NOMENCLATURE) table
5 Figure 1-2: TYPICAL WIRING DIAGRAM
7 Added the following text to the SPECIFICATIONS:
DIGITAL INPUT
Voltage Range: 38.5 to 250 V AC
24 to 250 V DC
Frequency Range: 40 to 70 Hz
12 Added the following warning:
DO NOT CHANGE SETTINGS WHILE THE MDP IS IN OPERATION AND ITS PROTEC-
TIVE ELEMENTS IN USE. TAKE THE RELAY OUT OF SERVICE BEFORE MAKING ANY
SETTING CHANGES.
--- Added MODBUS PROTOCOL chapter
--- Added FREQUENTLY ASKED QUESTIONS Appendix
--- Added REVISION HISTORY Appendix
--- Added WARRANTY page, website information, and INDEX
