24 3 SERIES RETROFIT – INSTRUCTION MANUAL
DOWNLOADING AND SAVING MIF II OR MIV II SETPOINT FILES CHAPTER 2: CONVERTING SETTINGS FILES
2.1 Downloading and saving MIF II or MIV II setpoint files
Use the following procedure to download and save MIF II or MIV II setpoint files to a local
PC.
4.Note the location of the saved setpoint file. Two files will be generated, *.txt and *.ajs,
and both are necessary for converting to *.sr3 setting file.
1. Start the EnerVista MII Setup software.
Note
Only MIF II or MIV II setpoint files from EnerVista MII Setup version 2.70 and firmware
versions listed at the beginning of this chapter are supported for conversion. Older file
versions must be converted to the latest version using the latest EnerVista MII Setup
software.
To download the latest MII setup software, see http://www.gegridsolutions.com
Ensure that the site and corresponding device(s) have been properly defined and
configured. (Refer to the MIF II Instruction Manual for more information on the
Enervista MII Setup software.)
2. Obtain settings information from the connected relay using File > Get info from relay.
3. The EnerVista MII Setup software prompts for the name and destination path of the
setpoint file. The corresponding file extension is automatically assigned (*.ajs). Press
Save to complete the process. After a few seconds of data retrieval the file is saved.
4. Note the location of the saved setpoint file. Two files will be generated: *.txt and *.ajs.
Both files are needed for conversion to a *.sr3 setting file.
