64 3 SERIES RETROFIT – INSTRUCTION MANUAL
239 WIRING CHAPTER 4: ELECTRICAL INSTALLATION
Note 1: The 239 relay with MOD 509 is designed to provide Ground directional protection.
Similar protection can be obtained using the 339 relay on neutral instantaneous protection
using the either current or voltage or both.
43 Access sw + Programmable
from B1 to B10
44 Restart sw + Programmable
from B1 to B10
45 Reset sw + Programmable
from B1 to B10
46 Option 1 sw + Programmable
from B1 to B10
47 Option 2 sw + Programmable
from B1 to B10
48 RTD shield A11
49 RTD1 hot B8
50 RTD1 comp A8
51 RTD1 ret B11
52 RTD2 hot B9
53 RTD2 comp A9
54 RTD2 ret B11
55 RTD3 hot B10
56 RTD3 comp A10
57 RTD3 ret B11
58 Vcom polarizing
(MOD 509)
Note 1
Table 4–19:
239 Terminal Wiring Connection 339 Terminal
