GE NX-1308E - Caddx 8 Zone LED Keypad User Manual

NX-8 Control
39
NX-8 PROGRAMMING WORKSHEETS
(Factory defaults for segments are in bold italics text and "Quick Start" locations are identified with the L symbol.)
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
L
0 13 PHONE #1 14-14-14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-14-14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
L
1 13 PHONE #1, ACCOUNT CODE 10 - 10 - 10 - 10 - 10 - 10 _ _ _ _ _ _
L
2 13 PHONE #1, REPORTING FORMAT 0 _
L
3 13 PHONE #1, DIAL ATTEMPTS
BACKUP CONTROL
8
0
_
_
PHONE #1, SELECTING EVENTS TO REPORT TO PHONE #1
Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program)
4 14
1
2
3
4
5
6
7
8
Alarms and Restores
Open/Close
Bypass
Zone Trouble
Power Trouble (AC Failure or Low Battery)
Siren & Telephone Fault
Test Reports
Program, Download, & Log Full
1
2
3
4
5
6
7
8
Tampers
Short Circuit & Ground Fault
Sensor Lost
Sensor Low Battery
Expander Trouble
Failure To Communicate
Reserved
Reserved
PHONE #1, SELECTING WHICH PARTITIONS REPORT TO PHONE #1
Segment #1 (Circle Numbers To Program)
5 15
1
2
3
4
5
6
7
8
Partition #1
Partition #2
Partition #3
Partition #4
Partition #5
Partition #6
Partition #7
Partition #8
L
6 15 PHONE #2 14-14-14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-14-14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
L
7 15 PHONE #2, ACCOUNT CODE 10 - 10 - 10 - 10 - 10 - 10 _ _ _ _ _ _
L
8 15 PHONE #2, REPORTING
FORMAT
0 _
9 15 PHONE #2, DIAL ATTEMPTS
BACKUP CONTROL
8
0
_
_
PHONE #2, SELECTING EVENTS TO REPORT TO PHONE #2
Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program)
10 16
1
2
3
4
5
6
7
8
Alarms and Restores
Open/Close
Bypass
Zone Trouble
Power Trouble (AC Failure or Low Battery)
Siren & Telephone Fault
Test Reports
Program, Download, & Log Full
1
2
3
4
5
6
7
8
Tampers
Short Circuit & Ground Fault
Sensor Lost
Sensor Low Battery
Expander Trouble
Failure To Communicate
Reserved
Reserved
PHONE #2, SELECTING WHICH PARTITIONS REPORT TO PHONE #2
Segment #1 (Circle Numbers To Program)
11 16
1
2
3
4
5
6
7
8
Partition #1
Partition #2
Partition #3
Partition #4
Partition #5
Partition #6
Partition #7
Partition #8

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
