APPENDIX 2 REPORTING ZONE CODES IN SIA OR CONTACT ID
The NX-8 has the ability to report SIA level 1 transmissions to either or both phone numbers. Each report in SIA consists of an
Event Code and a Zone or User ID. The Zone ID will be the zone number that is in alarm. The event code will come from the
chart below and be programmed in the zone type event code.
Programmed Event Code
SIA Code Description
0 HA Holdup Alarm
1 FA Fire Alarm
2 PA Panic alarm
3 BA Burglary Alarm
4 BA Burglary Alarm
5 BA Burglary Alarm
6 UA Untyped Alarm
7 BA Burglary Alarm
8 BA Burglary Alarm
9 UA Untyped Alarm
10 HA Holdup Alarm
11 MA Medical Alarm
12 PA Panic alarm
13 TA Tamper Alarm
14 RP Periodic Test
15 GA Gas Alarm
16 KA Heat Alarm
17 WA Water Alarm
18 QA Emergency Alarm
19 SA Sprinkler Alarm
20 ZA Freeze Alarm
The NX-8 has the ability to report Ademco Contact ID transmissions. Each report in Contact ID consists of an Event Code and
a Zone ID. The zone ID is the zone that created the alarm. The event code will come from the chart below and be programmed
in the zone type event code.
Programmed Event Code
Contact ID Code Description
0 122 Silent Panic
1 110 Fire Alarm
2 120 Panic alarm
3 130 Burglary Alarm
4 131 Perimeter Alarm
5 132 Interior Alarm
6 133 24 Hour Burglary
7 134 Entry Alarm
8 135 Day/Night Alarm
9 150 Non Burglary 24 Hour
10 121 Duress Alarm
11 100 Medical Alarm
12 123 Audible Panic Alarm
13 137 Tamper Alarm
14 602 Periodic Test
15 151 Gas Detected
16 158 High Temp
17 154 Water Leakage
18 140 General Alarm
19 140 General Alarm
20 159 Low Temp

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
