NX-8 Control
52
APPENDIX 1 REPORTING FIXED CODES IN CONTACT ID AND SIA
The table below list the event codes sent for the following reports (if enabled) when using CONTACT ID or SIA formats.
REPORT
CONTACT ID SIA
MANUAL TEST 601 RX
AUTOTEST 602 RP
OPEN (user number) 401 OP
CLOSE (user number) 401 CL
CANCEL (user number) 406 OC
DOWNLOAD COMPLETE 412 RS
START PROGRAM 627 LB
END PROGRAM 628 LX
GROUND FAULT 310 GF
GROUND FAULT RESTORE 310 GK
RECENT CLOSE (user number) 401 CR
EXIT ERROR (user number) 457 EE
EVENT LOG FULL 605 JL
FAIL TO COMMUNICATE 354 RT
EXPANDER TROUBLE (device number) 333 ET
EXPANDER RESTORE (device number) 333 ER
TELEPHONE FAULT 351 LT
TELEPHONE RESTORE 351 LR
SIREN TAMPER (device number) 321 YA
SIREN RESTORE (device number) 321 YH
AUX POWER OVER CURRENT (device number) 312 YP
AUX POWER RESTORE (device number) 312 YQ
LOW BATTERY (device number) 309 YT
LOW BATTERY RESTORE (device number) 309 YR
AC FAIL (device number) 301 AT
AC RESTORE (device number) 301 AR
BOX TAMPER (device number) 137 TA
BOX TAMPER RESTORE (device number) 137 TR
KEYPAD TAMPER 137 TA
KEYPAD PANIC (audible) 120 PA
KEYPAD PANIC (silent) 121 HA
DURESS 121 HA
KEYPAD AUXILIARY 1 110 FA
KEYPAD AUXILIARY 2 100 MA
RF SENSOR LOST (zone number) 381 *T
RF SENSOR RESTORE (zone number) 381 *R
SENSOR LOW BATTERY (zone number) 384 XT
SENSOR BATTERY RESTORE (zone number) 384 XR
ZONE TROUBLE (zone number) 380 *T
ZONE TROUBLE RESTORE (zone number) 380 *R
ZONE TAMPER (zone number) 137 TA
ZONE TAMPER RESTORE (zone number) 137 TR
ZONE BYPASS (zone number) 570 *B
BYPASS RESTORE (zone number) 570 *U
THE NUMBER IN PARENTHESES FOLLOWING THE EVENT IS THE NUMBER THAT WILL BE REPORTED AS THE
ZONE NUMBER. IF THERE ARE NO PARENTHESES, THE ZONE WILL BE A0". SEE PAGE 54 FOR THE DEVICE
NUMBERS.
* The character transmitted in this slot will be the first character from the event code of the zone that is
bypassed or in trouble. (See locations 110 - 141)

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
