GE NX-1308E - Caddx 8 Zone LED Keypad User Manual

SPECIFICATIONS
OPERATING POWER 16.5 VAC 25, 40, or 50 VA Transformer
AUXILIARY POWER
w/25 VA Transformer 12 VDC Regulated 500 mA
w/40 or 50 VA Transformer 12 VDC Regulated 1 AMP
w/NX-320E Power Supply 12 VDC Regulated 2 AMPS + Control
Panel Power
LOOP RESISTANCE
Standard Loop 300 Ohms Maximum
2-Wire Smokes 30 Ohms Maximum
BUILT-IN SIREN DRIVER 2-tone (Temporal and Yelp)
LOOP RESPONSE Selectable 50mS or 500mS
OPERATING TEMPERATURE 32 to 120 degrees F
LED KEYPAD
Current Draw 130 mA max.
Zones Normal w/o Sounder 55 mA
Dimensions 6.4" Wide
4.0" High
1.1" Deep
NX-148E LCD KEYPAD
Current Draw 110 mA max.
w/o Sounder 75 mA
Dimensions 6.4" Wide
5.3" High
1.0" Deep
METAL ENCLOSURE DIMENSION 11.25" Wide
11.25" High
3.50" Deep
SHIPPING WEIGHT 9 lbs.
Main Phone 800-727-2339 Technical Support 888-437-3287
Outside the US 903-845-6941 Sales & Literature 800-547-2556
Main Fax 903-845-6811
Web: www.gesecurity.com
NX-8 INSTALLATION MANUAL
NX8IT05 REV. T (FEB2005)
UL approved
for ANSI/SIA
CP-01-2000

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
