NX-8 Control
54
APPENDIX 3 EXPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE
The tables below list the device numbers that will be reported for trouble conditions.
Device Device # reported
NX-8 Control Panel 0 See page 53 for possible report codes.
NX-534E Two Way Listen-In 64
NX-540E “Operator” 40
NX-591E Cellemetry Interface 76
NX-870E Fire Supervision 9
KEYPADS
KEYPAD PART 1 PART 2 PART 3 PART 4 PART 5 PART 6 PART 7 PART 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
HARDWIRE EXPANDER (NX-216) OUTPUT MODULE (NX-508E)
Starting zone number
Expander # reported
Address & Dip Switch Setting
Zone 9 (All switches off) 22 24 (Switch 1 & 2 on)
Zone 9 (Switch 1 on) 23 25 (Switch 3 on)
Zone 17 (Switch 2 on) 16 26 (Switch 1 & 3 on)
Zone 25 (Switch 1 & 2 on) 17 27 (Switch 2 & 3 on)
Zone 33 (Switch 3 on) 18 28 (Switch 1,2,&3 on)
Zone 41 (Switch 1 & 3 on) 19 29 (All switches off)
30 (Switch 1 on)
31 (Switch 2 on)
WIRELESS RECEIVER (NX-448E) REMOTE POWER SUPPLY (NX-320E)
Switch Setting Expander # reported Address & Dip Switch Setting
All switches off 35 84 (All switches off)
Switch 1 on 36 85 (Switch 1 on)
Switch 2 on 37 86 (Switch 2 on)
Switches 1 & 2 on 38 87 (Switch 1 & 2 on)
Switch 3 on 39 88 (Switch 3 on)
Switches 1 & 3 on 32 89 (Switch 1 & 3 on)
Switches 2 & 3 on 33 90 (Switch 2 & 3 on)
Switch 1, 2 & 3 on 34 91 (Switches 1, 2, & 3 on)

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
