GE ZTS Series User Manual


ZTSH/ZTSDH/ZTSDL/ZTSHL/ZTSDHL
Standard Control Panel Layout (SSRCP)
SPARE
J1 J2 J3 J4 J5 J6 J7 J8 J9 J10 J11
JUMPERS
XE
RT
CR
XN
B1
B2 B3
VFSM
W
U
T
P1
Figure 27
JUMPER
CONNECTS
POINTS
REMOVE WHEN
ACCESSORIES USED
J1 23, 23A B1
J2 23A, 23B B2
J3 23B, 23C B3
J4 23C, 23Z JIN, TS, C/D
J5 23Z, 27 T, Y N
J6 25, 25Z T3, R4
J7 28, 28Z S1, C, C/D
J8 28Z, 29 P1 & U
J9 33A, 33Y ER1, 2, 3, J1E
J10 33Z, 37 W
J11 35, 35Z R4, W3
Panel Mount Control Relays
ATS
T
U
W
L2
P1
B3
RT
B2
B1
VFSM
Figure 28
NORMAL
SOURCE 1
L1
EMER
SOURCE 2
PRESS TO TEST
HOLD UNTIL
TRANSFER
TS
TAG
DESCRIPTION
L1
L2
ATS Source 2 (EMER) Position Indicator
A
TS Source 1 (NORMAL) Position Indicator
Lens Source 1 (NORMAL)
Lens Source 2 (EMER)
Bulb Socket
Source 2 (EMER) Bulb
Source 1 (NORMAL) Bulb
TS Test Switch
Operator
, Momentary
Contact Block N.C.
Contact Mounting Base
CR
CE1
CN1
XN XE
GE Zenith Controls
ZTS/ZTSD/ZTSH/ZTSDH/ZTSDL/ZTSHL/ZTSDHL Operation and Maintenance Manual (71R-3000)
35
