gefran ADV20 series User Manual

ADV20 QS, V1.02 15
Italiano English
Parameter Explanation Settings
Factory
Setting
NOTE
03.13
Display the Status of
Relay
Read only ##
Group 4 Input Function Parameters
a04.00
Keypad
Potentiometer Bias
0.0 to 100.0 % 0.0
a04.01
Keypad
Potentiometer Bias
Polarity
0: Positive bias
1: Negative bias
00
a04.02
Keypad
Potentiometer Gain
0.1 to 200.0 % 100.0
0: No negative bias command
04.03
Keypad
Potentiometer
Negative Bias,
Reverse Motion
Enable/Disable
1: Negative bias: REV motion enabled
0
04.04 2-wire/3-wire
Operation Control
Modes
0: 2-wire: FWD/STOP, REV/STOP
1: 2-wire: FWD/REV, RUN/STOP
2: 3-wire operation
0
1
04.05 Multi-function Input
Terminal (MI3)
2
04.06 Multi-function Input
Terminal (MI4)
3
04.07 Multi-function Input
Terminal (MI5)
4
04.08 Multi-function Input
Terminal (MI6)
0: No function
1: Multi-Step speed command 1
2: Multi-Step speed command 2
3: Multi-Step speed command 3
4: Multi-Step speed command 4
5: External reset
6: Accel/Decel inhibit
7: Accel/Decel time selection command
8: Jog Operation
9: External base block
10: Up: Increment master frequency
11: Down: Decrement master frequency
12: Counter Trigger Signal
13: Counter reset
14: E.F. External Fault Input
15: PID function disabled
16: Output shutoff stop
17: Parameter lock enable
18: Operation command selection (external
terminals)
19: Operation command selection(keypad)
20: Operation command
selection(communication)
21: FWD/REV command
22: Source of second frequency command
04.09
Multi-function Input
Contact Selection
Bit0:MI1
Bit1:MI2
Bit2:MI3
Bit3:MI4
Bit4:MI5
Bit5:MI6
0:N.O., 1:N.C.
P.S.: MI1 to MI3 will be invalid when it is 3-
wire control.
0
