gefran GFX4-IR Configuration And Programming Manual

3780415F_MSW_GFX4-IR_05-2019_ENG
661
dg.t
R/W
Refresh rate SSR SHORT
The alarm activates after 3 seconds.
1...999 sec
10
662
dg.f
R/W
Time lter for NO_VOLTAGE, SSR_OPEN and NO_CURRENT alarms
Note: set a value not less than cycle time.
0...99 sec
10
Power Fault ALARMS (SSR_SHORT, NO_VOLTAGE, SSR_OPEN and NO_CURRENT)
660
hd.2
R/W
Enable POWER_FAULT alarms
0
+ 32 alarms with memory
Table of Power Fault alarms
Read state
96
bit
State of alarm
SSR_SHORT phase 1
OFF = Alarm disabled
ON = Alarm active
R
97
bit
State of alarm
SSR_SHORT phase 2
OFF = Alarm disabled
ON = Alarm active
R
98
bit
State of alarm
SSR_SHORT phase 3
OFF = Alarm disabled
ON = Alarm active
R
99
bit
State of alarm
NO_VOLTAGE phase 1
OFF = Alarm disabled
ON = Alarm active
R
100
bit
State of alarm
NO_VOLTAGE phase 2
OFF = Alarm disabled
ON = Alarm active
R
101
bit
State of alarm
NO_VOLTAGE phase 3
OFF = Alarm disabled
ON = Alarm active
R
102
bit
State of alarm
NO_CURRENT phase 1
OFF = Alarm disabled
ON = Alarm active
R
103
bit
State of alarm
NO_CURRENT phase 2
OFF = Alarm disabled
ON = Alarm active
R
104
bit
State of alarm
NO_CURRENT phase 3
OFF = Alarm disabled
ON = Alarm active
R
105
bit
Reset SSR_SHORT
/ NO_VOLTAGE /
NO_CURRENT alarms
OFF = -
ON = Reset memory
R/W
SSR_ SHORT NO_ VOLTAGE NO_CURRENT
0
1 X
2 X
3 X X
4
5 X
6 X
7 X X
8 X
9 X X
10 X X
11 X X X
12 X
13 X X
14 X X
15 X X X
With 3-phase load
With 3-phase load
With 3-phase load
With 3-phase load
With 3-phase load
With 3-phase load
