gefran GFX4-IR Configuration And Programming Manual

66
80415F_MSW_GFX4-IR_05-2019_ENG
508
(.xd1
R
Self-diagnosis error code
for auxiliary input
In correspondence to the SV value on the GFX-OP display, the digits indicate bit values
as follows:
- TENS (auxiliary inputs) correspond to bits 0 to 1
- ONES (fieldbus interface) correspond to bits 6 to 15
bit Correspondance Value
0 = 1 INPUT AUX absent 0
1 = 1 INPUT AUX TC / 60mV 1
2 -
3 = 1 FIELDBUS ETH4 (ProNet)
4 = 1 FIELDBUS ETH5
5 = 1 FIELDBUS ETH6
6 = 1 FIELDBUS absent O
7 = 1 FIELDBUS Modbus m
8 = 1 FIELDBUS Probus P
9 = 1 FIELDBUS CanOpen C
10 = 1 FIELDBUS DeviceNet d
11 = 1 FIELDBUS Ethernet E
12 = 1 FIELDBUS Euromap66 c
13 = 1 FIELDBUS ETH3 3
14 = 1 FIELDBUS ETH2 (Ethercat) 2
15 = 1 FIELDBUS ETH1 (Ethernet IP) 1
Table of auxiliary input errors
HW/SW INFORMATION
The following data registers can be used to identify the controller HW/SW and check its operation.
122
UPD
R
Software version code
606
Er.2
R
Self-diagnosis
error code for auxiliary input
0 No Error
1 Lo (process variable value < Lo.S)
2 Hi (process variable value > Hi.S)
3 ERR [third wire interrupted for PT100 or input values below minimum
limits (ex. for TC with connection error)]
4 SBR (probe interrupted or input values beyond maximum limits)
85
Err
R
Self-diagnosis
error code for main input
Table of main input errors
190
(.xd
R Hardware configuration codes
At value SV on the GFX-OP display, the figures indicate the value of bits as follows:
- THOUSANDS and HUNDREDS
(Power GFX4-IR) correspond to bits 7 to 9
- TENS (COOL outputs) correspond to bits 1 to 4
bit Correspondence Value
0 = 1 COOL OUTPUT absent 0
1 = 1 COOL OUTPUT relay r
2 = 1 COOL OUTPUT logic d
3 = 1 COOL OUTPUT continuous 0...20mA / 0...10V t
4 = 1 COOL OUTPUT triac 250Vac 1A c
5 -
6 -
7 = 1 GFX4-IR 30 kW 30
8 = 1 GFX4-IR 60 kW 60
9 = 1 GFX4-IR 80 kW 80
Table of hardware conguration codes
693
697
Upd.F
R Fieldbus software version
695
(od.F
R Fieldbus node
696
bAu.F
R Fieldbus baudrate
Profibus
bAu.F baudrate
0 12.00 Mbit/s
1 6.00 Mbit/s
2 3.00 Mbit/s
3 1.50 Mbit/s
4 500.00 Kbit/s
5 187.50 Kbit/s
6 93.75 Kbit/s
7 45.45 Kbit/s
8 19.20 Kbit/s
9 9.60 Kbit/s
Canopen
bAu.F baudrate
0 1000 Kbit/s
1 800 Kbit/s
2 500 Kbit/s
3 250 Kbit/s
4 125 Kbit/s
5 100 Kbit/s
6 50 Kbit/s
7 20 Kbit/s
8 10 Kbit/s
Devicenet
bAu.F baudrate
0 125 Kbit/s
1 250 Kbit/s
2 500 Kbit/s
Ethernet
bAu.F baudrate
0 100 Mbit/s
1 10 Mbit/s
894
F.SIZE
R/W
I/O dimension for eldbus
0
I/O table data dimesion for Fieldbus
0 16 words input + 16 words output
1 24 words input + 24 words output
