GEM 1436 cPos User Manual

www.gemu-group.com64 / 76GEMÜ 1436 cPos
17 Troubleshooting
16.2.3.9.1 Explanation of parameters: 5 Communication
Service
1
SetBasics
2
SetFunction
3
SetCalibration
4
Return
6
SETUP
Communication
5
16.2.3.9.1.1 13.5.1. Setting the fieldbus parameters
Fieldbus:
Only available in fieldbus version
For details see separate operating instructions.
16.2.3.9.1.2 13.5.2. Setting the communication parameters
NOTICE
▶ For details on how to use the GEMÜ e.sy-com interface and operating the browser see separate operating instructions.
WebServer:
Submenu for setting the communication parameters
RS 232:
Defines the type of RS 232 connection
Auto with connection to a PC/laptop or industrial modem
Serial with connection to a PC/laptop
Bdrate RS:
Defines the transmission rate of the serial connection.
Bdrate RS 38400 baud
57600 baud
115,200 baud (default setting)
17 Troubleshooting
No. Error message Description Condition for the occurrence
of the error
Error cause
000 NO ERROR There are no errors - -
010 Iw < 4 mA
Error
The set value signal is
lower than 4mA
The positioner is in auto-
matic mode
A cable break at the set value in-
put
011 Iw > 20 mA
Error
The set value signal is
higher than 20mA
The positioner is in auto-
matic mode
The set value signal is higher
than 20mA
012 Ix < 4 mA
Error
The actual value signal is
lower than 4mA
The process controller is
active
A cable break at the actual value
input
013 Ix > 20 mA
Error
The actual value signal is
higher than 20mA
The process controller is
active
The actual value signal is higher
than 20mA
