Closing the Master Control
032-0207-EN Rev 0
1-8
Closing the Master Control
1. Close the door and reinstall the two Phillips screws.
2. Reinstall the outer cover and the top cover.
3. For Local configurations, continue to step 4.
For Remote configurations, skip to step 5.
4. For the Master Control Touch Panel that is mounted directly to the
Master Control:
a. Put the cables back in the Strain Relief.
b. Pull the control cable and the coil-cord back through the cutout for
the cables when reinstalling the outer cover.
c. Connect the control cable and the exposure switch coil-cord to the
Master Control Touch Panel before attaching the panel to the outer
cover.
d. Skip to step 6.
5. Install the Blank Plate in the outer cover.
6. Make sure all parts and screws are back on.
7. Restore power to the equipment:
– FOR A SYSTEM WITH A LINE CORD (120 V ac only), plug in the
line cord.
– FOR A HARD-WIRED SYSTEM, reconnect the mains supply
(external power source) and use a meter to verify the mains supply is
connected properly.
8. Turn ON the power switch.
Tools Required: No. 2 Phillips Screwdriver
