Opening the Master Control
032-0207-EN Rev 0
1-2
Master Control
Opening the Master Control
There are 2 configurations for the Master Control:
• Local - Master Control Touch Panel is mounted directly to the Master
Control
• Remote - Master Control Touch Panel is mounted on a wall plate
1. Turn OFF the power switch.
2. Disconnect the external power source:
– FOR A SYSTEM WITH A LINE CORD (120 V ac only), unplug the
line cord.
– FOR A HARD-WIRED SYSTEM, disconnect the mains supply
(external power source) and use a meter to verify the mains supply is
disconnected.
3. For Local configurations, continue with Local Configuration
Instructions.
For Remote configurations, continue with Remote Configuration
Instructions on page 1-6.
Local Configuration Instructions
To open the Master Control when the Master Control Touch Panel is
mounted directly, (Local configuration):
1. Remove the Master Control Touch Panel:
(Continued)
Tools Required: No. 2 Phillips Screwdriver
