Gigabyte GA-MA785GT-UD3H User Manual

Hardware Installation - 10 -
1-2 Product Specications
CPU

Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus

5200 MT/s
Chipset

 North Bridge: AMD 785G


 South Bridge: AMD SB710
Memory

4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)

Dual channel memory architecture

Support for DDR3 1666(O.C.)/1333/1066 MHz memory modules


 (Go to GIGABYTE's website for the latest memory support list.)
Onboard Graphics

Integrated in the North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port
(Note 2) (Note 3)
- 1 x HDMI port
(Note 3)
Audio
   
Realtek ALC889A codec

High Denition Audio

2/4/5.1/7.1-channel

Support for Dolby
®
Home Theater
    
Support for S/PDIF In/Out

Support for CD In
LAN

1 x RTL8111C chip (10/100/1000 Mbit)
Expansion Slots

1 x PCI Express x16 slot, running at x16 (PCIEX16_1)
(Note 4)

1 x PCI Express x16 slot, running at x4 (PCIEX4_1)
(Note 5)
(The PCIEX16_1 and PCIEX4_1 slots support ATI Hybrid CrossFireX
™
technology and conform to PCI Express 2.0 standard.)

3 x PCI Express x1 slots (The PCIEX1_2 and PCIEX1_3 slots share bandwidth
with the PCIEX4_1 slot.)
(Note 5)

2 x PCI slots
Storage Interface

South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 10, and JBOD

iTE IT8718 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
USB

Integrated in the South Bridge

Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets
connected to the internal USB headers)

Gigabyte GA-MA785GT-UD3H Specifications

General

Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Power fan connector	Yes
Number of SATA connectors	6
Number of Parallel ATA connectors	1
Controller interface type	SATA
Controller 2nd interface type	IDE
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista/ XP
RAID levels	0, 1, 1+0, JBOD
LAN controller	Realtek RTL8111C
Networking features	Gigabit Ethernet

Weight and Dimensions

Depth	229 mm
Width	305 mm
