Gigabyte GA-MA78LMT-S2 User Manual

Unique Features - 70 -
Available functions in EasyTune 6 may differ by motherboard model. Grayed-out area(s) indicates that the item is
notcongurableorthefunctionisnotsupported.
Incorrectly doing overclock/overvoltage may result in damage to the hardware components such as CPU, chipset,
and memory and reduce the useful life of these components. Before you do the overclock/overvoltage, make sure
that you fully know each function of EasyTune 6, or system instability or other unexpected results may occur.
4-3 EasyTune 6
GIGABYTE'sEasyTune6 isasimpleand easy-to-useinterfacethatallowsuserstone-tune theirsystem
settings or do overclock/overvoltage in Windows environment. The user-friendly EasyTune 6 interface also
includes tabbed pages for CPU and memory information, letting users read their system-related information
without the need to install additional software.
The EasyTune 6 Interface
Tabs Information
Tab Function
The CPU tab provides information on the installed CPU and motherboard.
The Memory tab provides information on the installed memory module(s). You can select memory
    moduleonaspecicslottoseeitsinformation.
The Tuner tab allows you to change system clock settings and voltages.
• Easy mode allows you to adjust the CPU FSB only.
• Advanced mode allows you to individually change system clock settings and voltages settings
using the sliders.
• Easy Boost is an easy-to-use auto-overclocking function
(Note)
. When activated, the system
     automaticallyexperimentsallsortsofoverclockingcongurationstillithangs.Afterrestart,the
     systemwilloperatewiththeoptimumcongurationstestedtolettheCPUreachthebest
overclocking performance.
• Saveallowsyoutosavethecurrentsettingstoanewprole(.txtle).
• Loadallowsyoutoloadprevioussettingsfromaprole.   
After making changes in Easy mode/Advanced mode, be sure to click Set for these changes to take
effect or click Default to restore to default values.
The Graphics tab allows you to change the core clock and memory clock for your ATI or NVIDIA
graphics card.
The Smart tab allows you to specify a C.I.A.2 level and a Smart Fan mode. Smart Fan Advance Mode
allows the CPU fan speed to be changed linearly based on the CPU temperature thresholds you set.
The HW Monitor tab allows you to monitor hardware temperature, voltage and fan speed and set
temperature/fan speed alarm. You can choose the alert sound from the buzzer or use your own sound
    le(.wavle).
(Note) Before enabling Easy Boost, right-click the EasyTune 6 icon inthenoticationarea.SelectAuto overclock
last tune on the next reboottoallowthesystemtoworkwiththeoptimumoverclockingcongurationafterrestart.
