Gigabyte GA-MA790XT-UD4P User Manual

GA-MA790XT-UD4P Motherboard - 10 -
1-2 Product Specifications
CPU  Support for Socket AM3 processors:
AMD Phenom
TM
II X3 processor/AMD Phenom
TM
II X4 processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus  5200/2000 MT/s
Chipset  North Bridge: AMD 790X
 South Bridge: AMD SB750
Memory  4 x 1.5V DDR3 DIMM sockets supporting up to 1 6 GB of system memory
(Note 1)
 Dual channel memory architecture
 Support for DDR3 1666(O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio  Realtek ALC889A codec
 High Definition Audio
 2/4/5.1/7.1-channel
 Support for Dolby
®
Home Theater
(Note 2)
 Support for S/PDIF In/Out
 Support for CD In
LAN  Realtek 8111DL chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16_1)
 1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
(Note 3)
(The PCIEX16_1 and PCIEX8_1 slots support ATI CrossFireX
TM
technology
and conform to PCI Express 2.0 standard.)
 3 x PCI Express x1 slots
 2 x PCI slots
Storage Interface  South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, RAID 10 and JBOD
 GIGABYTE SATA2 chip:
- 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1 and JBOD
 iTE IT8720 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394  T.I. TSB43AB23 chip
 Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a bracket
connected to the internal IEEE 1394a header)
USB  Integrated in the South Bridge
 Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)

Gigabyte GA-MA790XT-UD4P Specifications

General

Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	2
Power fan connector	Yes
Number of COM connectors	1
Number of SATA connectors	8
Controller interface type	SATA
Controller 2nd interface type	IDE
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Audio chip	Realtek ALC889
Motherboard chipset	AMD 790X
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista/ XP
PCI Express x1 slots	3
RAID levels	0, 1, 5, 10, JBOD
LAN controller	Realtek RTL8111DL
Networking features	10/100/1000 Mbit/s

Weight and Dimensions

Depth	233 mm
Width	305 mm
