Global Sentinel User Manual

Global Power Technologies ASSEMBLY AND INSTALLATION
302842 Rev0 | Sentinel Page 14 of 61
Prepare the following tools and supplies before installing the Sentinel TEG:
 1 – DC Voltmeter, accurate to ±0.1V
 2 – Adjustable wrenches that open to 25mm (1 inch)
 1 – Hex key set (SAE) including 3/16", 5/32", 1/8", 3/32", 5/64"
 1 – #2 Phillips Screwdriver
 1 – flat blade screwdriver
 1 – Tube bender suitable for 1/4” SS tubing
 Thread sealant suitable for fuel connections
3.2 UNPACKING AND LIFTING
WARNING!
Check the Sentinel TEG for any signs of damage before beginning assembly. Some
damages can make the unit inoperable. Consult Global Power Technologies before
operating a TEG with any signs of damage.
Unpack the Sentinel TEG from the shipping crate and inspect the unit for any damage that may have
occurred during shipping. Keep the crate until the Sentinel TEG is operational.
 1 – Sentinel TEG including an electronics assembly kit, GPT Part Number 303139, taped to the
inside floor of the instrumentation enclosure, come with following items:
 2 – Ceramic battery fuses (GPT Part Number 302722), 1 spare and 1 to be installed on
the start-up battery pack
 2 – Terminal forks, 18-22 AWG, Red, for low voltage alarm connections [ + LV ALARM – ]
 2 – Terminal forks, 14-16 AWG, Blue, for customer load connections [ + TEG OUT – ]
 1 – Terminal ring, 14-16 AWG, Blue, for customer load connection to grounding terminal
inside the electronics enclosure
 1 – Terminal ring, 10-12 AWG, Yellow, for bonding the site ground to the Sentinel TEG via
the ground screw located on the lower left-hand side on the outside of instrumentation
enclosure
 1 – Start Assist Tool, see Section 4.2 for details
 1 – Regulator subassembly and thread sealant (JET-LUBE TF-15)
 1 – Fuel filter
 2 – Fuel filter cartridges, for installation in the Fuel filter
 1 – Mounting bracket for the Fuel filter
 1 – Pack of hardware required for the Fuel filter
 1 - ¼” NPT ball valve
 1 - ¼” NPT x 2” long brass nipple
 2 - ¾” MNPT x ¼” FNPT brass reducer
 1- ¼” tube x ¼” MNPT SS connector
 4 – ¼-20 x 1” SS hex head bolts
 4 – ¼” SS flat washers
 4 – ¼” SS lock spring washers
 4 – ¼-20 SS hex nuts
 4 – 2” U-bolt muffler clamps, for pole mounting
 1 – 36” long section of 1/4" tubing, fuel line for Fuel filter to TEG regulator (requires bending on
site to suit installation)
