Global Sentinel User Manual

Global Power Technologies ASSEMBLY AND INSTALLATION
302842 Rev0 | Sentinel Page 15 of 61
During shipment, the Sentinel TEG is supported by a piece of plywood that is attached to the crate
with 4 wood screws to protect the Sentinel TEG during transportation. Remove these 4 wood screws
before lifting the Sentinel TEG from the crate.
The Sentinel TEG can be lifted with at least two people. Refer to the weight specifications listed in
APPENDIX A — WEIGHT AND DIMENSIONS for reference. The Sentinel TEG can be lifted in either a
horizontal or vertical position. If lifting equipment such as a hoist or forklift is available, lifting slings
can be used. Two lifting slings are recommended, with one each on the left and right side of the
generator such that they are positioned under the fin ducts and instrumentation enclosure from front
to back. The slings should be positioned on the bottom on either side of the bottom insulation cover
assembly, see Figure 5.
Figure 5 – Lifting Sling Locations
