0020167175_01 - 02/13 - Glow-worm
12.2 Installation settings
• Push in and hold the button for more than 7 seconds to
access the confi guration menu. The screen displays "0".
• Press the
button 4 times. The screen displays "96". This is
the installer's password.
• Press
to validate. The screen displays a fl ashing and
alternating "d." and "00".
• Press
or button to access the parameter to modify.
• Press
button to modify the value of the parameter and
select with the
or keys.
• Press button to confi rm and save the changes.
• Press and hold the
button for more than 7 seconds to
exit.
Code Parameter Unit Description Factory setting
Modifi able
parameter
d.00 Maximum heating power kW
Choose a value: ULTIMATE 30c > 6 to 25
and ULTIMATE 35c > 8 to 30.
25 (ULTIMATE 30c)
30 (ULTIMATE 35c)
yes
d.01 Pump over-run time - heating min Choose a value between 2 and 60 5 yes
d.20 Maximum temperature setting for domestic hot water °C
The recommended maximum temperature
setting for DHW is 60°C. Choose a value
suitable for your needs.
60 yes
d.34 Speed of fan rpm
Fan speed is displayed between 0 and 99.
Multiply the display value by 100.
-no
d.36 Domestic hot water fl ow
l/
min.
Display domestic hot water fl ow. - no
d.40 Heating fl ow temperature °C Display the heating fl ow temperature. - no
d.41 Heating return temperature °C Display the heating return temperature. - no
d.43 Heating curve K
See the instructions for the external sensor
connected to the appliance.
1.2 yes
d.47 Exterior temperature °C
Display the temperature measured by the
external sensor.
-no
d.67
Time remaining before the end of the anti-cycle in
heating mode.
min.
Display the time remaining before the end of
the anti-cycle
-no
d.71 Maximum temperature setting for heating outlet °C Select a value between 50°C and 80°C. 75 yes
d.90 Detection of eBUS controller -
0 = Not detected
1 = Detected
-no
12.3 After Sales Service settings
• Press and hold the button for more than 7 seconds to
access the confi guration menu. The screen displays "0".
• Press
or button and enter the After Sales Service
password.
• Press
to validate. The screen displays a fl ashing and
alternating "d." and "00".
• Press
or button to access the parameter to modify.
• Press
button to modify the value of the parameter and
select with the or keys.
• Press
button to confi rm and save the changes.
• Press and hold the
button for more than 3 seconds to
exit the confi guration menu.
Code Parameter Unit Description
Factory
setting
Modifi able
parameter
d.08 Current state of the 230V room thermostat -
230V room thermostat :
0 = open (no heating),
1 = closed (heating mode).
-no
d.09 Flow temperature set point from external eBus control °C External eBus set value. - no
d.10 Heating pump status -
0 = off
1 = on
-no
d.16 Current state of the 24V room thermostat °C
0 = open (no heating),
1 = closed (heating mode)
-no
d.17 Flow or Return temperature control °C
Temperature regulation on fl ow (radiator) or return
(under-fl oor heating) temperature sensor.
0yes
d.22 DHW demand active (tapping) -
0 = off
1 = on
-no
d.23 Central heating mode -
0 = CH not available (summer mode)
1 = CH available (winter mode)
-no
d.33 Speed setpoint of fan rpm
Fan speed is displayed between 0 and 99.
Multiply the displayed value by 100.
-no
INSTALLATION
- 25 -
