TECHNICAL DATA
5 ULTIMATE c
Boiler, type C13, C33, C43
Description Unit 30 35
Gas category ll
2H3P
ll
2H3P
SEDBUK rating 2009 % 88.8% 88.9%
Heating
Maximum heating input power kW 25 30.6
Minimum heating output power at
80/60°C (P min.)
kW 5.9 8.5
Maximum heating output power at
80/60°C (P max.)
kW 24.5 30
Minimum heating output power at
50/30°C (P min.)
kW 6.5 9.2
Maximum heating output power at
50/30°C (P max.)
kW 26.4 32.5
Minimum heating temperature °C 10 10
Maximum heating temperature °C 80 80
Minimum heating fl ow rate l/h 400 400
Content of heating expansion
vessel
l8 8
gallons 1.76 1.76
Heating expansion vessel preset
pressure
bar 0.75 0.75
psi 10.9 10.9
Maximum heating system volume
(approx)
l 160 160
Heating safety valve preset
pressure (PMS)
bar 3 3
lbf/in² 36/3 36/3
Domestic Hot Water
Minimum DHW output power (P
min.)
kW 6.1 8.7
Maximum DHW output power (P
max.)
kW 30.6 35.7
Maximum DHW temperature °C 60 60
Specifi c fl ow rate (∆T of 35 K) l/min 12.5 14.6
Minimum inlet water pressure
bar 0.3 0.3
psi 4.3 4.3
Maximum inlet water pressure
bar 10 10
psi 145 145
Combustion
Appliance NOx class 5 5
Electrical
Electrical supply V/Hz
230V /
50Hz
230V /
50Hz
Standby mode electrical power W 6 6
Operational mode electrical power
(Max)
W 151 151
Internal fuse rating on main PCB A 2 2
Index of electrical protection (EN
60529)
IPX4D IPX4D
Description Unit 30 35
Gas connection Ø O.D. mm 15 (copper) 15 (copper)
Heating flow and return connection
Ø O.D.
mm 22 (copper) 22 (copper)
Domestic Hot Water connection
Ø O.D.
mm 15 (copper) 15 (copper)
Condensate connection Ø I.D. mm
Pushfi t
Plastic
Pushfi t
Plastic
Safety valve discharge connection
Ø O.D.
mm 15 (copper) 15 (copper)
Lift weight
kg 37,7 38,3
lb 82 84.8
Total weight (installed) kg 41 43
Number of CE certifi cate
1312 BU
5335
1312 BV
5336
Description Unit 30 35
Natural Gas G 20 (15 °C, 1013.25 mbar)
Maximum DHW gas fl ow rate
m
3
/h
3,24 3,77
Maximum heating gas fl ow rate
m
3
/h
2,65 3,24
Minimum gas fl ow rate
m
3
/h
0,65 0,92
CO
2
at Qmax DHW + "tolerance
case ON"
% 9.2 ± 0.3% 9.2 ± 0.3%
CO
2
at Qmax DHW + "tolerance
case OFF"
% 9.0 ± 0.2% 9.0 ± 0.2%
CO
2
at Qmin +
"tolerance case ON"
% 8.9 ± 0.3% 8.9 ± 0.3%
CO
2
at Qmin +
"tolerance case OFF"
% 8.7 ± 0.2% 8.7 ± 0.2%
Inlet pressure mbar 20 20
Propane Gas G 31 (15 °C, 1013.25 mbar)
Maximum DHW gas fl ow rate kg/h 2,38 2,77
Maximum heating gas fl ow rate kg/h 1,94 2,37
Minimum gas fl ow rate kg/h 0.47 0.67
CO
2
at Qmax DHW + "tolerance
case ON"
%
10.3 ±
0.3%
10.3 ±
0.3%
CO
2
at Qmax DHW + "tolerance
case OFF"
%
10.1 ±
0.3%
10.1 ±
0.3%
CO
2
at Qmin +
"tolerance case ON"
% 9.8 ± 0.3% 9.8 ± 0.3%
CO
2
at Qmin +
"tolerance case OFF"
% 9.6 ± 0.2% 9.6 ± 0.2%
Inlet pressure mbar 37 37
TECHNICAL DATA
- 7 -
