32
User Manual V1.6-2022-01-05 02 Installation Instructions
2.8 Wiring System
CT1
Meter CT Communication
AC Breaker
Load
AC Breaker
PE
N
L2
L1
Grid
Power Meter
Main Breaker
CT2
Battery
DC Breaker
NTC
BMS
PV Strings
Back-up Breaker
120V
Loads
240V
Loads
Auto-transformer
PE
N
L2
L1
1
2
6
5
4
3
Power ON
Power OFF
Turn on
Turn o
1
2
4
3
1
2
4
3
