Graco Reactor E-20 Series User Manual

Motor Control Diagnostic Codes
14 312066ZAD
Motor Control Diagnostic Codes
Motor control diagnostic codes E21 through E29 appear
on pressure display.
There are two types of motor control codes: alarms and
warnings. Alarms take priority over warnings.
Alarms
Alarms turn off Reactor. Turn main power OFF
then ON to clear.
Warnings
Reactor will continue to run. Press to clear. A
warning will not recur for a predetermined amount of
time (varies for different war nings), or until main power
is turned OFF then ON .
Alarms can also be cleared, except for code 23, by
pressing .
Code Code Name Alarm (A) or
Warning (W)
Corrective
Action
page
21 No transducer (compo-
nent A)
A
16
22 No transducer (compo-
nent B)
A
16
23 High fluid pressure A
16
24 Pressure imbalance A/W (to
select, see
page 37)
16
25 High line voltage A
18
26 Low line voltage A
18
27 High motor temperature A
18
28 High current A
29
29 Brush wear W
19
30 Momentary loss of
communication
-
19
31 Motor control failure A
18
32 Motor control
overtemperature
A
19
99 Loss of communication -
19
