Technical Data

312066ZAD 75

Technical Data

All other brand names or marks are used for identification purposes and are trademarks of their respective owners.

Category Data

Maximum Fluid Working Pressure Models E-20 and E-30: 2000 psi (14 MPa, 140 bar)

Model E-XP1: 2500 psi (17.2 MPa, 172 bar)

Model E-XP2: 3500 psi (24.1 MPa, 241 bar)

Maximum Fluid Temperature 190°F (88°C)

Maximum Output Model E-20: 20 lb/min (9 kg/min)

Model E-30: 30 lb/min (13.5 kg/min)

Model E-XP1: 1 gpm (3.8 liter/min)

Model E-XP2: 2 gpm (7.6 liter/min)

Output per Cycle (A and B) Model E-20 and E-XP1: 0.0104 gal. (0.0395 liter)

Model E-30: 0.0272 gal. (0.1034 liter)

Model E-XP2: 0.0203 gal. (.0771 liter)

Line Voltage Requirement Parts 259024, 259025, 259026, 259028, 259057: 195-264 Vac, 50/60 Hz

Parts 259029, 259030, 259031, 259032, 259059: 338-457 Vac, 50/60 Hz

Parts 259033, 259034, 259035, 259036, 259058: 195-264 Vac, 50/60 Hz

Amperage Requirement See Table 1, page 12.

Heater Power Model E-20: 6000 Watts

Model E-30 and E-XP1: 10200 Watts

Models E-XP2 and E-30 with 15.3kW of heat: 15300 Watts

Sound Power, per ISO 9614-2 Model E-20: 80 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)

Model E-30: 93.5 dB(A) at 1000 psi (7 MPa, 70 bar), 3.0 gpm (11.4 lpm)

Model E-XP1: 80 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)

Model E-XP2: 83.5 dB(A) at 3000 psi (21 MPa, 210 bar), 1.0 gpm (3.8 lpm)

Sound Pressure, 1 m from equipment Model E-20: 70.2 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)

Model E-30: 83.6 dB(A) at 1000 psi (7 MPa, 70 bar), 3.0 gpm (11.4 lpm)

Model E-XP1: 70.2 dB(A) at 2000 psi (14 MPa, 140 bar), 0.5 gpm (1.9 lpm)

Model E-XP2: 73.6 dB(A) at 3000 psi (21 MPa, 210 bar), 1.0 gpm (3.8 lpm)

Fluid Inlets 3/4 npt(f), with 3/4 npsm(f) union

Fluid Outlets Component A (ISO): -8 (1/2 in.) JIC, with -5 (5/16 in.) JIC adapter

Component B (RES): -10 (5/8 in.) JIC, with -6 (3/8 in.) JIC adapter

Fluid Circulation Ports 1/4 npsm(m), with plastic tubing; 250 psi (1.75 MPa, 17.5 bar) maximum

Weight Model E-20 and E-XP1: 342 lb (155 kg)

Model E-30: 400 lb (181kg)

Models E-XP2 and E-30 with 15.3kW of heat: 438 lb (198 kg)

Wetted Parts Aluminum, stainless steel, zinc plated, carbon steel, brass, carbide, chrome,

chemically resistant o-rings, PTFE, ultra-high molecular weight polyethylene
