Technical Data
60 334606B
Technical Data
DutyMax EH230DI Standard Series
US Metric
Maximum fluid working pressure . . . . . . . . 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity . . . . . . . . . . . . 1.25 gallons 4.75 liters
Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.0 HP
2.2 kW
Voltage, Amperage Frequency Phase
220 VAC, 15.0 A,
50 Hz, 1 phase
220 VAC, 15.0 A
50 Hz, 1 phase
Maximum tip size . . . . . . . . . . . . . . . . . . . . 0.039
Maximum free-flow delivery . . . . . . . . . . . . 1.56 gpm 5.9 l/min
Hose connection. . . . . . . . . . . . . . . . . . . . . 3/8 npsm (f)
Cycles per gallon 80 21.1
Sound Levels
(Measured at maximum normal load conditions)
Engine HP . . . . . . . . . . . . . . . . . . . . . . . . .
3.0
Sound pressure
80 dBa
Sound power
95
Inlet/Outlet Sizes
Fluid inlet size in. . . . . . . . . . . . . . . . . . . . . 1 npt (m)
Fluid outlet size in. . . . . . . . . . . . . . . . . . . . 3/8 npt (m)
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197 lb. 89 kg
Width
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26.5 in. 67 cm
Length (Handle bar retracted)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47.7 in. 121 cm
Height (Handle bar retracted)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35.5 in. 90 cm
