Graco Standard Series User Manual

Technical Data
62 334606B
DutyMax GH230 Standard Series
US Metric
Maximum fluid working pressure. . . . . . . . . 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity . . . . . . . . . . . . 1.25 gallons 4.75 liters
Maximum hydraulic pressure . . . . . . . . . . . 1855 psi 12.8 MPa,128 bar
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
200 cc (6.5 HP)
Maximum tip size. . . . . . . . . . . . . . . . . . . . . 0.053
Maximum free-flow delivery. . . . . . . . . . . . . 2.35 gpm 10.7 l/min
Hose connection . . . . . . . . . . . . . . . . . . . . . 3/8 npsm (m)
Noise (dBa)
Maximum sound pressure . . . . . . . . . . . . . .
96 dBa
Maximum sound power
110 dBa
Inlet/Outlet Sizes
Fluid inlet size . . . . . . . . . . . . . . . . . . . . . . . 1 5/16-12 UN-ZA
Fluid outlet size . . . . . . . . . . . . . . . . . . . . . . 3/8 npt (f)
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199 lbs. 90 kg
Width
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26.5 in. 67 cm
Length
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47.7 in. 121 cm
Height (Handle bar retracted)
35.5 in. 90 cm

Graco Standard Series Specifications

General

Brand	Graco
Model	Standard Series
Category	Paint Sprayer
Language	English
