Graco Standard Series User Manual

Technical Data
66 334606B
DutyMax GH230 ProContractor Series
US Metric
Maximum fluid working pressure. . . . . . . . . 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity . . . . . . . . . . . . 1.25 gallons 4.75 liters
Maximum hydraulic pressure . . . . . . . . . . . 1855 psi 12.8 MPa,128 bar
Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
200 cc (6.5 HP)
Maximum tip size. . . . . . . . . . . . . . . . . . . . . 0.053
Maximum free-flow delivery. . . . . . . . . . . . . 2.35 gpm 10.7 l/min
Hose connection . . . . . . . . . . . . . . . . . . . . . 3/8 npsm (m)
Noise (dBa)
Maximum sound pressure . . . . . . . . . . . . . .
96 dBa
Maximum sound power
110 dBa
Inlet/Outlet Sizes
Fluid inlet size . . . . . . . . . . . . . . . . . . . . . . . 1 5/16-12 UN-ZA
Fluid outlet size . . . . . . . . . . . . . . . . . . . . . . 3/8 npt (f)
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229 lbs. 104 kg
Width
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26.5 in. 67 cm
Length
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 in. 132 cm
Height (Hose Reel Up)
39 in. 99 cm
OEM Kit
Paint/Hydraulic pressure ratio . . . . . . . . . . . 1.78:1
Max cycle rate 145 cpm
User Supplied Input
Max hydraulic pressure . . . . . . . . . . . . . . . . 1855 psi 12.8 MPa,128 bar
Hydraulic flow required in free-flow 6.60 gpm 25.0 l/min
Unit Output
Max fluid Pressure 3300 psi 22.8 MPa, 228 bar
Max flow 3.0 gpm 11.4 l/min
Weight
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 lb. 15.9 kg
Width
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.94 in. 227 mm
Depth
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.38 in. 137 mm
Height
28.80 in. 732 mm
