Gree GMV-ND22PLS/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
208
Above data is subject to change without notice,pls reference the SP in global service website.
5.13 Wall Mounted type Indoor Unit
Exploded View of GMV-N22G/A3A-K、GMV-N28G/A3A-K
31
Crank
` 73012005
1
32
Stepping Motor
` 1521210101
1
33
Display Board
` 30568131
1
34
Pinboard
` 30278000001
1
35
Terminal Board
` 42010268
1
36
Electric Board
` 20112116
1
37
Main Board
` 30226000080
1
38
Magnetic Ring
` 49010104
1
39
Shield Cover of Electric Box
Sub-assy
` 01592169
1
40
Remote Controller
` 30510589
1
No.
Name of part
For the following unit
Unit
Product Code
GMV-N22G/A3A-K
CM100N1350
GMV-N28G/A3A-K
CM100N1340
Part code
Quantity
1
Receiver Window
'22432230
1
2
Guide Louver
'10512157
1
3
Front Panel B1
'20012122S
1
4
Filter Sub-Assy
1112220403
1
