English (GB)
13
12. Technical data
12.1 Dimensions
Dimensions with floor stand (H x W x D) [cm]: 82 x 33 x 28
Dimensions without floor stand (H x W x D) [cm]: 62 x 33 x 24
Observe the special dimensions for wall mounting. See fig. 1.
12.2 Weights
12.3 Ambient conditions
* Product must be drained.
12.3.1 Lighting
There must be a flicker and glare free general light of or higher
than 300 lux available in the working area.
12.4 Lifetime
The product lifetime depends on the application and how well it is
maintained. However, the product has an expected lifetime of 5-8
years when used within normal operating conditions and if it is
maintained in accordance with these instructions.
12.5 Electrical data
12.6 Medium and hydraulic data
Medium: Drinking water. For other applications, contact
Grundfos.
Maximum length of sample line: 5 m.
Inlet pressure:
• Standard:
– Maximum: 10 bar
– Minimum: 2 bar.
• With pump module (optional):
– Maximum: 2 bar
– Minimum: 0 bar.
Temperature of medium (non-condensing):
• Maximum: 40 °C
• Minimum: 5 °C.
Required pipe connection for the sample line:
• 1/2" G female with ball valve.
12.7 Internet connection
GSM connection. SIM card connected to 3G network is installed.
12.8 Data access
• Online (web/app)
• Offline (download)
• SCADA integration via API.
12.9 Measuring principle
• 3D scanning optics: Automatic intelligent microscope
• total bacteria count per ml
• total non-bacteria count per ml
• measuring range: 0-1,000,000 objects/ml (bacteria and non-
bacteria).
12.10 Batch sample taking through flow cell
• Wide channels to prevent clogging
– channel width: 2 mm
• scanned volume: 6 μl
• water use per sample: 150-250 ml (with standard settings)
• automatic continuous sample taking with a cycle time of
approximately 10 minutes.
12.11 Built-in system diagnostics
• Flow cell pressure sensor
• sample temperature sensor
• flow cell fouling monitoring.
12.12 Noise
Airborne noise emitted by the product:
13. Disposal
The product must be sent back to the manufacturer for scrapping.
The product must not be disposed of as unsorted household
waste.
Subject to alterations.
Description
Weight
[kg]
BACMON bacteria sensor 20.38
Pump module (self-priming) 1.16
Pump module with prefilter (self-priming) 1.40
Prefilter module 0.29
Suction filter (tank solution) 0.04
Extension antenna (15 m) 1.67
Floor stand 4.63
Permissible ambient temperatures (minimum/maximum)
Transport* [°C] 0/40
Storage* [°C] 0/40
Operation [°C] 5/40
Maximum relative humidity (non-condensing) [%] 95
Maximum altitude [m] 2000
The camera module must never be exposed to
moisture or liquid.
Direct sunlight can cause damage to the product.
Exposure to direct sunlight can cause changes in
colour as well as material deformations and cracks.
Do not expose the system to direct sunlight!
Supply voltage [VAC] 110-240
Frequency [Hz] 44-66
Maximum power consumption [W] 15
Enclosure class IP54
Electrical safety class I
Variant Noise [db(A)]
Without pump module << 70
With pump module 79
