6. Product introduction
6.1 Intended use
The GRUNDFOS BACMON bacteria sensor is to be used for
analysis of water using a specially developed imaging technique.
The use of the product is in indoor, frost-free waterworks
buildings and pumping stations.
6.2 Identification
6.2.1 Nameplate
The nameplate is placed on the side of the product enclosure.
Fig. 3 Nameplate
6.3 Product overview
Fig. 4 Product overview
The product must not be used for any other purpose
than the one mentioned above. For other uses,
please contact Grundfos.
TM06 6389 3716
TM06 6390 3516
Pos. Description
1 Wireless GSM communication connection
2 Operating panel
3 Alarm and status LEDs
4
Water analysis cabinet
With reagentless, patented, 3D scanning optics
5
Hydraulic parts
There are product variants with different hydraulic
accessories. The figure is just an example.
6 Stand (accessory)
7 Control cabinet
8 Main switch
9 Extension antenna (accessory)
10 Front plate
