Operating
parameter
Description
Status Shows whether a pump is started or stopped.
Controlled by
CU 362 (system), manually by switch (Auto/On/
Off) or via SCADA.
Operation
Shows how the system is being
controlled: automatically or manually.
Operating
hours
Number of hours the pump has been in operation
(can be changed if another pump is installed).
Latest runtime The latest operating period of the pump.
Time since
service
The time elapsed since the pump was last
serviced (can be reset by Grundfos Service).
Time for
service
Time until the next service is due.
Number of
starts
Number of pump starts since the pump was
installed/connected (can be changed if another
pump is installed).
Number of
starts/hour
Number of pump starts in the last hour.
Average flow
Requires an analog level sensor or flow sensor.
See section about pit configuration and flow
calculation.
Latest flow
The calculated/measured flow of the last pump
that was running.
Number of flow
measurements
Requires an analog level sensor.
See section about pit configuration and flow
calculation.
Motor current
The actual average current consumption. 0 A
when the pump stops.
Latest current
The current value when the pump stopped. The
value updates when the pump is running.
Requires a current sensor/ammeter, an MP 204
or a CUE.
Start level
Requires an analog level sensor (not shown with
alternating operation).
Operating
parameter
Description
Stop level Requires an analog level sensor.
MP 204
When an MP 204 is installed, the following
parameters can be read:
• MP 204, voltage
• MP 204, current
• MP 204, current asymmetry
• MP 204, cos φ
• MP 204, power
• MP 204, energy
• MP 204, insulation resistance
• MP 204, temperature Pt
• MP 204, temperature PTC (Active or Not
active)
• MP 204, temperature Tempcon.
IO 113
When an IO 113 is installed, the following
parameters can be read:
• IO 113, motor temperature (Pt sensor)
• IO 113, water in oil (WIO sensor)
• IO 113, insulation resistance
• IO 113, moisture in motor (Active or Not
active).
CUE or VFD
When either a CUE or VFD is installed, the
following parameters can be read:
• VFD, output freq. (CU 362 → CUE/VFD)
• VFD, economy freq.
• VFD, economy level
• VFD, state (VFD not controlled, Stopped,
Reverse start, Start flushing, Normal, Run
flushing, Stop flushing, Specific-energy test)
• VFD, voltage
• VFD, current
• VFD, power
• VFD, energy
• VFD, torque.
Related information
5. The "Status" menu
8.1.6 Modules installed
5.4 GSM/GPRS
This display shows the status of the GSM modem.
The display can be used to check the antenna conditions and for
fault finding.
SIM card status
Shows the SIM card status message sent to the system.
Signal strength
A graph shows the actual signal strength.
• If the signal strength is unknown, "–" is displayed.
• If there is no signal, "No signal" is displayed.
GPRS state
Shows the GPRS network state.
Statistics
Displays the number of sent and received SMS messages and the
amount (kB) of sent and received GPRS data.
GPRS network
The current network IP address.
Path:
Status > System > GSM/GPRS
11
