Operation
During calibration, analog outputs can remain active, held, or transferred to a preset mA
value.
4.6 Relay Options
Refer to System Setup on page 31 for more information on the relay options menu.
4.7 Data Event Logging Options
The sc100 provides three data logs (one for each sensor and one for calculated values)
and three event logs (one for each sensor and one for the controller). The data logs store
the measurement data at selected intervals. The event log stores a variety of events that
occur on the devices such as configuration changes, alarms, and warning conditions. The
data logs are stored in a packed binary format and the event logs are stored in a CSV
format. The logs can be downloaded through the digital network port, the IrDA port, or
through the service port using the service cable LZX887.
4.5.3 Release Outputs
Step Select Menu Level Confirm
1 MAIN MENU —
2 TEST/MAINT
3 HOLD OUTPUTS
4 ACTIVATION
5 RELEASE
6 Main Menu or Main Measurement Screen —
4.6.1 Navigating to the Relay Options Menu
Step Select Menu Level/Instructions Confirm
1 MAIN MENU —
2 SYSTEM SETUP
3 RELAY SETUP
4 SELECT RELAY
5 Customize the options, refer to System Setup on page 31.
6 Main Menu or Main Measurement Screen when Relay options are configured. —
