6
Installation guide
Door lock structure
1
2
3
4
5
6
7
8
9
11
10
1. Front panel (1pc)
2. Spindle (1pc)
3. Connection bolt (2pcs)
4. Cylinder (1pc)
5. Mortise (1pc)
6. Mortise fixing screw (2pcs)
7. Cylinder fixing screw (1pc)
8. Back panel (1pc)
9. Battery cover (1pc)
10. Back panel screw (2pcs)
11. Battery cover fixing screw (1pc)
