Häfele DL6600 User Manual

7
Installation guide
Installation steps
Step 1:
Install the mortise and cylinder
Step 2:
Install the front panel
Note: The arrow mark must be aligned with
the right or left open direction arrow mark
Note: Firstly, install the connection bolts
on the front panel. Second, install the front
panel to the door (Connect the wire correctly.
Do not misplace the matching holes)

Häfele DL6600 Specifications

General

Brand	Häfele
Model	DL6600
Category	Door locks
Language	English
