4 - System setup
4.99
Application Map Screen - Zoom to Detail
A. GPS Status
B. Ground Covered
C. Ground Speed
D. Diagnostics button
E. Display Legend
F. Manual Fluid Control
G. Home button
H. Map View button
I. AutoTerrain/AutoHeight/AutoSlant button
J. AutoSwath button
K. AutoSteer button
L. Main ON/OFF switch status
Legend Select
During Area Logging Application operations, the Map screen displays coverage in the Legend.
Use the drop-down menu at the top to select your
product. Other items at this screen include:
• Coverage
Shows the area where you have already
applied a product.
• Clear Map
Permanently removes all map data from the
active field operation.
• Load Reference
Load a map from a previous operation
performed in that field to view as a
background map.
Load
Reference
Legend Select
Coverage
Clear Map
