Harman Kardon AVR 1610 User Manual

36
AVR
Specifications
Specifications
Audio Section
Stereo power: AVR 1710/AVR 171: 100W per channel,
two channels driven @ 6/8 ohms, 1kHz,
<0.9% THD
AVR 1610/AVR 161: 85W per channel, two
channels driven @ 6/8 ohms, 1kHz, <0.9%
THD
Multichannel power: AVR 1710/AVR 171: 100W per channel,
two channels driven @ 6/8 ohms, 1kHz,
<0.9% THD
AVR 1610/AVR 161: 85W per channel, two
channels driven @ 6/8 ohms, 1kHz, <0.9%
THD
Input sensitivity/impedance: 250mV/27k ohms
Signal-to-noise ratio (IHF-A): 100dB
Surround system adjacent channel
separation:
Dolby Pro Logic/DPLII: 40dB
Dolby Digital: 55dB
DTS: 55dB
Frequency response (@ 1W): 10Hz – 130kHz (+0dB/–3dB)
High instantaneous current
capability (HCC):
±40 amps (AVR 1710/AVR 171);
±29 amps (AVR 1610/AVR 161)
Transient intermodulation
distortion (TIM):
Unmeasurable
Slew rate: 40V/sec
FM Tuner Section
Frequency range: 87.5 – 108.0MHz
Usable sensitivity IHF: 1.3µV/13.2dBf
Signal-to-noise ratio (mono/stereo): 70dB/68dB
Distortion (mono/stereo): 0.2%/0.3%
Stereo separation: 40dB @ 1kHz
Selectivity (±400kHz): 70dB
Image rejection: 80dB
IF rejection: 80dB
AM Tuner Section
Frequency range: 520 – 1710kHz (AVR 1710/AVR 1610)
522 – 1620kHz (AVR 170/AVR 160)
Signal-to-noise ratio: 38dB
Usable sensitivity (loop):
500µV
Distortion (1kHz, 50% mod): 1.0%
Selectivity (±10kHz): 30dB
Bluetooth Section
Frequency range: 2402MHz - 2480MHz
Transmitter power: 0-4dBm
Modulation:
GFSK, π/4-DQPSK, 8-DPSK
Functions: Streaming audio play, supports Bluetooth
3.0, A2DP v1.2, AVRCP v1.4
Video Section
Television format: NTSC (AVR 1710/AVR 1610);
PAL (AVR 171/AVR 161)
Input level/impedance: 1Vp-p/75 ohms
Output level/impedance: 1Vp-p/75 ohms
Video frequency response (composite
video):
10Hz – 8MHz (–3dB)
HDMI: HDMI 1.4 with 4k x 2k bypass
General Specifications
Power requirement: 120V AC/60Hz (AVR 1710/AVR 1610);
220V – 240V AC/50Hz – 60Hz (AVR 171/
AVR 161)
Power consumption:
<0.5W (standby);
510W maximum (AVR 1710/AVR 171);
450W maximum (AVR 1610/AVR 161)
Dimensions (W x H x D):
17-5/16" x 4-3/4" x 11-3/16"
(440mm x 121mm x 300mm)
Weight
(AVR 1710/AVR 171): 11 lb (5.1kg)
(AVR 1610/AVR 161): 10 lb (4.6kg)
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.

Harman Kardon AVR 1610 Specifications

Audio Specifications

stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	100dB
surround system adjacent channel separation (Dolby Pro Logic/DPLII)	40dB
surround system adjacent channel separation (Dolby Digital)	55dB
surround system adjacent channel separation (DTS)	55dB
frequency response (@1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±29 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	80dB

AM Tuner Specifications

frequency range	520kHz – 1, 610kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	425µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI support	up to 4K x 2K

General Specifications

power requirement	120V AC/60Hz
power consumption	<0.5W (standby); 450W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10lb (4.6kg)
