Harman Kardon AVR 1610 User Manual

37
ENGLISH
AVR
Appendix
Appendix – Default settings, worksheets, remote product codes
Table A1 – Recommended Source Component Connections
Device Type AVR Source
Digital Audio
Connection
Analog Audio Connection
Video
Connections
Roku Streaming Stick or other
portable device; HDMI-capable
device
MHL (AVR 1710/AVR 171/
AVR 1610/AVR 161)
HDMI 1/MHL Analog 1 or 2 HDMI 1/MHL
DVD Audio/Video, SACD,
Blu-ray Disc, HD-DVD player
Disc HDMI 2 Analog 1 or 2 HDMI 2
Cable TV, satellite TV, HDTV
or other device that delivers
television programs
Cable/Sat HDMI 3 Analog 1 or 2 HDMI 3
DVR or set-top box STB HDMI 4 Analog 1 or 2 HDMI 4
Video-game console Game HDMI 5 Analog 1 or 2 HDMI 5
Any audio or video device,
e.g., CD player, camcorder,
cassette deck
Aux Coaxial or Optical Analog 1 or 2
Composite Video 1 or 2 (not used
for audio-only devices)
Any audio-only playback device
(e.g. CD player, cassette deck)
Audio Coaxial or Optical Analog 1 or 2 None
iPod, iPhone, iPad or USB
memory stick
USB/iPod USB N/A N/A
Appendix

Harman Kardon AVR 1610 Specifications

Audio Specifications

stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	100dB
surround system adjacent channel separation (Dolby Pro Logic/DPLII)	40dB
surround system adjacent channel separation (Dolby Digital)	55dB
surround system adjacent channel separation (DTS)	55dB
frequency response (@1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±29 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	80dB

AM Tuner Specifications

frequency range	520kHz – 1, 610kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	425µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI support	up to 4K x 2K

General Specifications

power requirement	120V AC/60Hz
power consumption	<0.5W (standby); 450W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10lb (4.6kg)
